Specifications
System
Type: 3.0 way
Enclosure: Midrange sealed cork enclosure, Woofers down vented box
Loudspeakers
Drivers: High-end quality
Tweeter: 1,1" DAD™ Arrow Point extended frequency tweeter, Copper shorting ring
Midrange: 1x 6,5" Camelia midrange, Copper shorting ring
Woofer: 2 x 6,5" woofers, Aluminum demodulation ring
Crossover Points
Frequency: 280 Hz - 2500 Hz
Frequency Response
Range: 35 Hz - 40.000 Hz
Sensitivity
Rating: 89 dB SPL (2.83 V/1m)
Nominal Impedance
Impedance: 4 Ohm
Recommended Power Amplifier
Power Range: 50 W - 320 W
Dimensions
Product (HxWxD):
1088 x 308 x 415 mm (42.8 x 12.13 x 16.34 in) per speaker
With Packaging (HxWxD):
1190 x 420 x 530 mm (46.85 x 16.54 x 20.87 in)
Weight
Product:
33,40 kg (73.63 lb) per speaker
Packaging:
75,2 kg (165.8 lb) per two cartons with one speaker
